Small Shrink Packaging Machine/Shrink Machine/Shrink Tunnel model 101 engineer mansy global mark
Parameters Small Shrink Packaging Machine/Shrink Machine/Shrink Tunnel model 101 engineer mansy global mark
| Model | 101 Engineer Mansy Brand |
| Power supply | 220V 50Hz |
| Power | 5KW |
| Conveyor speed | Up to 10m/min |
| Conveyor loading | 25kg |
| Shrinking Film | POF, PVC, PP, POF, PVC, PP. PE |
Tunnel size
| Model | Tunnel size | Price |
| 101 – 1626 | 800 X 260 X 160 mm | 400 $ |
| 101 – 1530 | 800 X 300 X 150 mm | 500 $ |
| 101 – 2040 | 830 X 400 X 200 mm | 600 $ |
| 101 – 3545 | 850 X 450 X 350 mm | 700 $ |
Product Description Small Shrink Packaging Machine/Shrink Machine/Shrink Tunnel model 101 engineer mansy global mark
It uses the shrink wrap in the product or package outside, through heating bind tightly shrink film products or packaging, it shows the appearance of items, improve product sales, increased sense of beauty and value
Widely used in food, medicine, hardware tools, daily necessities, electrical appliances, books, fruit, and other items packaging industry.
Automatic shrink packaging machine is a mechanical device and pneumatic components combined by the PLC and other peripheral circuits controlled automatic packaging equipment
The device is an actuator cylinder. The two five-way solenoid valve to control the forward and backward
Work position cylinder by magnetic switches and proximity switch detects and feedback to the PLC, the PLC sends a control command to a corresponding cylinder valve through the program to control the operation of the cylinder
Advantages: Small Shrink Packaging Machine/Shrink Machine/Shrink Tunnel model 101 engineer mansy global mark
1.Shrink packaging machine and winding machine because the same power consumption is large, so the input power supply must be greater than the nominal power of contraction on the nameplate, or easy to burn line or electrical components.
2.Like baler machine must be grounded as to protect the personal safety.
3.Each machine shipped with a cable connected to the power line, the end portion of the identification code with a power lead must be connected correctly, illegal operation may cause electric shock.
4.When the machine predetermined voltage three-phase 380V power supply, you must enter the zero line, that is the standard three-phase four-wire devices such as other packaging vacuum packaging machine. Otherwise, the machine does not work, and can easily burn internal electrical components.
5.Machine must be installed horizontally, otherwise it will shorten the life of the heating pipe. Machine belt transmission, its tilt installation will cause the belt off center.
6.When machine work for more than three months of continuously, heat shrink wire respond inspection chamber according to their degree of aging, as appropriate replacement.
7.When machine is working, hands and other parts of the operating personnel are not allowed contact with the operating parts of the machine, especially a high shrinkage temperature inside the chamber, it is easy to burn.
8.Packing work, you should turn off the heating switch, so that the feed motor and fan motor continues to run about 10 minutes, then cut off the entire power supply.
