semi automatic shrink over wrapping machine for aluminum MODEL 107 engineer mansy global mark
Technical Parameter semi automatic shrink over wrapping machine for aluminum MODEL 107 engineer mansy global mark
| Model | 107 Engineer Mansy Brand |
| Power supply | 380V/3Phase / 50-60HZ |
| Heater power | 5.0KW on start only , adjustable |
| Seal-cut time | 0-1 seconds, adjustable |
| Max. sealing dimension (L*W) | 450*350mm |
| Max. packing dimension (L*W*H) | 450*350*200mm |
| Machine size (L*W*H) | 2630*790*1440mm |
| Machine weight | 220KG |
| Packing size | 2070*870*1480mm |
| Price | 700 $ |
Specifications semi automatic shrink over wrapping machine for aluminum MODEL 107 engineer mansy global mark
L-bar heating shrink over wrapping machine
1. easy operation
2. simple adjust
3.CE certificate
4.oversea service
Characteristics semi automatic shrink over wrapping machine for aluminum MODEL 107 engineer mansy global mark
1.High temperature and sticky free L bar sealing knife, sealing action without smoking and burned. Sealed part is tidy and clean.
- Covering Teflon on the sealing knife.
- After sealing action, packing product go in the shrink tunnel automatically by the conveyor belt.
- Conveyor belt is adjustable on the high by a hand wheel.
- BTL-450A has a manual/auto switch. When choose auto function, Whole sealing action controlled by cylinder automatically, with fast packing speed.
- Double electromagnets make stronger pressure.
- Adjustable film layer with needle device, it is able to fit different size film, max 550mm.
8.Sealing knife has hot protection device on.
