Manual operate bottle shrink wrapping machine model 107 engineer mansy mark
Main Technical Parameters Manual operate bottle shrink wrapping machine model 107 engineer mansy mark
| Model | 107 Engineer Mansy Brand |
| Power supply | 380V/3Phase / 50-60HZ |
| Heater power | 5.0KW on start only , adjustable |
| Seal-cut time | 0-1 seconds, adjustable |
| Max. sealing dimension (L*W) | 450*350mm |
| Max. packing dimension (L*W*H) | 450*350*200mm |
| Machine size (L*W*H) | 2630*790*1440mm |
| Machine weight | 220KG |
| Packing size | 2070*870*1480mm |
| Price | 700 $ |
Uses Manual operate bottle shrink wrapping machine model 107 engineer mansy mark
Suitable for electrical products, hardwares, softwares, food, printing products, medications, floor boards, ceramics etc’s packing
Performance Characteristics Manual operate bottle shrink wrapping machine model 107 engineer mansy mark
1.High temperature and sticky free L bar sealing knife, sealing action without smoking and burned. Sealed part is tidy and clean.
- Covering Teflon on the sealing knife.
- After sealing action, packing product go in the shrink tunnel automatically by the conveyor belt.
- Conveyor belt is adjustable on the high by a hand wheel.
- Double electromagnets make stronger pressure.
- Adjustable film layer with needle device, it is able to fit different size film, max 550mm.
7.Sealing knife has hot protection device on.
