Liquid or Softdrink Pneumatic Small Oil Bottle filling machine-E (30-500ml) model 403 Engineer mansy mark
Description Liquid or Softdrink Pneumatic Small Oil Bottle filling machine-E (30-500ml) model 403 Engineer mansy mark
Liquid or Softdrink Pneumatic filling machine (30-500ml)
Application
Our Pneumatic filling machine (30-500ml) is used for softdrink or other liquid .
Features Liquid or Softdrink Pneumatic Small Oil Bottle filling machine-E (30-500ml) model 403 Engineer mansy mark
50/60HZ (if you need 110v , please inform us ,then we will make 110v for you )
· Approximate Speed 20-40 pcs/min (depending on operator speed, product density, draw length, a fill speed, among others)
· All Parts in Contact with Product are Food Grade (SS 304/316)
· Includes one 30Liter Hopper
· Stainless Steel Construction
· Rugged Rotary Valve System Design
· Pneumatic Operation
· Silica gel O-ring System(cam bear 200 Celsius degree)
· Piston Feed Speed Adjustment
· No-drip Option Included and Installed
· Extremely Accurate (+/- 1%)
· Extremely Easy to Clean and Maintain
· Sanitary Stainless Steel Quick Disconnect Fittings
· Extremely Easy to Operate
· Quick Connect/Disconnect Pneumatic Fittings.
Control Panel
Semi Auto/Continuous Operation Selector Switch
Air Pressure Gauge
Air Intake Pressure Adjustment
Piston Volume Adjust
Accessory Liquid or Softdrink Pneumatic Small Oil Bottle filling machine-E (30-500ml) model 403 Engineer mansy mark
Air Consumption 3-5KG 0.4-0.6MPa
Wearing parts : Silica gel O-ring System (when delivery, I will prepared enough for you use in one year. Customer can buy in the future in their country)
Warranty : one year
