Instant Peanuts Sachet Packing/Filling Machine model 903 Engineer mansy international brand
0-1000g 0-40oz Granual/powder sachet filling sealing packing machine with Volumetric/counting Cup Filler
Model: 903
Use: Instant Peanuts Sachet Packing/Filling Machine model 903 Engineer mansy international brand
This machine is suitable for food, chemical, pharmaceutical, seasoning powder, granule and fine particle packing; particularly suitable for packaging milk powder, bean milk powder, sesame paste,sugar granule, wheat powder, dessicant and so on;
Characteristic: Instant Peanuts Sachet Packing/Filling Machine model 903 Engineer mansy international brand
It can full automatic carry out the process of sachet forming, filling and sealing, also can add date and batch number printing device, gas-flushing device, punch (a hole in the sachet for hanging to display the product).
Packaging products can select by tooth type cutting, scissors type flat cutting or with one notch cutting.
With easy tearing mouth device, for customers to open the packaging bag conveniently.
Using micro computer controller and Stepping motor with photoelectric switch position, easy to adjust length, precisely bag-making.
Using rotate measuring cup, lower the volume error, more accurate measurement.
Greatly enhance the stability of equipment, lower noise, cleaning convenient, reduce the maintenance cost.
Sealing tight, avoid leak or get damp.
Film feeding pinch mechanism, film with a little static can also be used.
High working speed, prevent Material leakage, no more dust.
Numerical control cutter can be added, it can set 2-99 bags(bags connected) automatic counting and then cutting.
When the roll film is end, machine will stop running automatically. It can automatic detect the fault.
Optional device: Instant Peanuts Sachet Packing/Filling Machine model 903 Engineer mansy international brand
- Date & batch printer
- Gas-flushing device
- Easy tear opening
- Numerical control cutter
5.Touch display menu
- Frequency control of motor speed
- Mixing system
- Keep warm system
Technical parameter: Instant Peanuts Sachet Packing/Filling Machine model 903 Engineer mansy international brand
| Model | 902 | 903 |
| Film width | Max 280mm, 14inch | Max 420mm, 18inch |
| Bag size(mm) | L:50-280mm,3-12inch | L:50-300mm,3-12inch |
| W:60-140mm,3-7inch | W:60-200mm,3-9inch | |
| Packing speed | 15-36 pcs/min | |
| Bag type | Back seal | |
| Packing range | 20-100g | 100-500ml, 100-500ml-1000 ml >1200 ml (custom-made) |
| Outer size(L x w x H) | 1200*1100*1800mm | 1200*1100*2000mm |
| Total power | 220V/110V AC 50HZ 1.2KW | 220V/110V AC 50HZ 2.2KW |
| Machine weigh | 320kg | 360kg |
