Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
Production Detail Introduce Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
Handheld Induction Sealing Machine
About machine
This machine is equiped with electromagnet induction heating system.
Throgh non-contact inductive heating, both the inductive film, aluminum film or composite based film will be tightly stuck onto the opening mouth of the containers after instantly thermal melting so as to reach the targt of sealing.
Specified model of this page is 201
Technique parameters Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
| Model | 201a | 201b | 201c |
| Voltage | AC220V/50HZ-60HZ, Support 110V as optional service | ||
| Power | 1200W (at least) | ||
| Work frequency | 50-80HZ | ||
| Required humidty | less than 90% PH (Non-condensing) | ||
| Working ambient temp | 10-40degrees | ||
| Sealing diameter | 15-50cm | 20-100cm | 70-130cm |
| Operation way | handheld | ||
| Dimensions | 260*345*165mm | ||
| Housing protective grade | IP20 | ||
| Safety standards | GB15579.1995 | ||
| Counting range | 0-9999 | ||
Operation instruction Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
1, Place setting, when work, no oil, dust, metal powder, and implement sensitive to 50-80HZ electromagnetic wave in surrounding.
2, Don’t place machine on metal or magnetic worktable, or lift the device height up 20cm against the worktable.
3, Insert the power plug into to the socket
4, Power on, the digital displayer will light up.
5, Setting parameter, set the individual working time via the timing button according to the actual size and texture of the sealing materials.
6, You can press the clear button to set reset the record.
Performance characteristics Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
- Imported MCU control, Siemens IGBT power tube, high efficiency, and low power consumption.
2 Automatically counting function effectively control the number of sealing.
- Reasonable structure design, easy to operate touch panel, simple.
- Automatic heating, over-voltage, over-current protection.
- Stable performance, long service life.
- Automatic shutdown function, no operation within 15 minutes, the machine automatically shut down
Application Electromagnet induction sealer tool, plastic container sealing machine, hand held bottle capping machine, manual capper, 15-50mm Model 201 engineer mansy international brand
Handheld induction sealing machine is a non-contact sealing machine, electromagnetic induction instantly generate high fever, aluminum foil fused in the neck of the bottle, this process applies to most sealed to avoid being contaminated items, the effective protection products, to avoid turningto sow, squeezing overflow accidents. This product is widely used in pharmaceutical, food, chemical, oil, pesticides, cosmetics, hotels, travel goods and light industries such as aluminum foil sealing the container. The material of the container is plastic bottles, glass bottles and other non-metallic material, such as: PE, PET, PP, PVC, ABS and so on.
Note: Don’t apply to metal container and cap!
Warm Tips
Product Service: All items displayed are availiable for shipping, you can leave us messages for any inquiry!
