Easy Operation Desktop Semi-automatic Labelling machine for round bottle model 831 Engineer mansy international mark
Product Description Easy Operation Desktop Semi-automatic Labelling machine for round bottle model 831 Engineer mansy international mark
Semi-automatic round bottle labelling machine
Working Principle
Imported intelligent high-accuracy magic eye and high reliable Computer chip program controller(PLC)control the label and the case, label, using rubber roller pinned bottle the non-drying label followed the bottle in the bottle and put on rotating.
Features Easy Operation Desktop Semi-automatic Labelling machine for round bottle model 831 Engineer mansy international mark
- Suitable for labeling round bottle in different sizes.
- Composed by main body, sending paper, receiving paper, bottle orientation etc parts.
- Putting the bottle to orientation part by manual and fix the bottle;
- all metal are made of 304 stainless steel with surface finishing and special treatment, which we can guarantee you very good quality
- small size labeling machine, very easy to operate
Advantages Easy Operation Desktop Semi-automatic Labelling machine for round bottle model 831 Engineer mansy international mark
- Efficiency is as high as 50 times/minutes.
- Labeling bottle adjustable, meet different before and after the workpiece labeling needs.
- Labeling effect is good, no bubble, no creases, grade high, to increase product competitiveness.
- Choose brand PLC and sensor etc electronic components, performance very stable.
- Modular design, convenient maintenance and repair costs low.
Specifications Easy Operation Desktop Semi-automatic Labelling machine for round bottle model 831 Engineer mansy international mark
| efficiency | ≤50pcs/min |
| precision | ±0.5mm |
| Applicable bottles of diameter | Φ20-150mm |
| Label roll | External diameter: 300mm;
Inner diameter: 75mm |
| Label size | width 8-150mm length 15-210mm (standard package)
(this is standard configuration, if you need longer than this, contact us firstly, It will be customized) |
| Power supply: | 20V/110V; 50HZ/60HZ |
| Power rating: | 120W |
| Machine size: | 650 (L) *450 (W) *450 (H) mm |
| Machine weight: | 25 kg |
