Continuous film sealing machine plastic bag package machine band sealer horizontal heating sealing machine model 301 engineer mansy international mark
Specifications: Continuous film sealing machine plastic bag package machine band sealer horizontal heating sealing machine model 301 engineer mansy international mark
Power: 220V 50HZ
Printing method: Stamps
Pulse Power: 850W
Sealing speed: 0-24mm
Sealing width: 12mm
Sealing thickness: =<0.80mm
Sealing Length: 0-infinity
Temperature range: 0-300 degrees
Transportation load: =<6KG
Dimensions: 840 * 380 * 270mm
Machine weight: 28KG
Notice: 110V need to charge extra 15usd !!
About this machine:
1: whether with copper heating modules and cooling modules: copper heating block allows faster and more uniform heating, it will not only improve sealing machine work efficiency, but also improve the quality of sealing.
2: if pure motor and gearbox with integrated motor: This motor is currently on the market a proprietary motor, motor and gearbox integrated structure, to solve the ordinary middle motors and gear couplings wear problems, thereby reducing small motor and gearbox load, so that the machine more durable, and high stability sound small machine also uses a pure aluminum gearbox!
3: Is conveyor chain conveyor: The machine uses a chain conveyor, and which is common machine conveyor belt that is common plastic strap, high-speed operation, the belt can easily break, so to you production inconvenience and increased maintenance costs we have this 770-type sealing machine using a metal chain conveyor, machine operation is stable and resistant to wear!
| Model number | 301 | Voltage (V) | 220v |
| Sealing electric power | 220*2w | Sealing width | 12 (MM) |
| Sealing speed
|
0-24 (MM) | Net weight(kg)
|
28kg |
| Transmission power | 80W | Frequency | 50Hz
|
| Temperature range
|
0-300 C (adjustable) | Film thickness max | =<0. 08 (MM) |
| Transport weight max | =<6 (KG) | Dimensions | 840*380*270 (MM) |
