Bottom price single nozzle cream filling machine 10 to 100g Model 404 engineer mansy mark
Features Bottom price single nozzle cream filling machine 10 to 100g Model 404 engineer mansy mark
This machine adopts pneumatic control and owns a wide application scope, simple measuring regulation, good shape and convenient cleaning, suitable for the explosion-proof unit.
1.Reasonable design, compact shape, simple operation
- The contact part with the material is all made of 304 or 316 stainless steel, meet the GMP requirements and Food grade.
- Filling volume, filling speed can be adjustable, filling accuracy is high.
- Adopt the anti-drip, Anti-drawing and lifting filling device.
Application Bottom price single nozzle cream filling machine 10 to 100g Model 404 engineer mansy mark
Suitable for medicine,daily life products, food and special industries.And it is an ideal device for adhesive fluid filling.
Principle Bottom price single nozzle cream filling machine 10 to 100g Model 404 engineer mansy mark
series of semi-automatic filling machine piston filler. Driven by a
cylinder and piston made from materials with FIVE-way valves control the flow of
materials, and magnetic reed switch control cylinder itinerary can be regulated
filling volume.
. Some contact materials are used 316 L stainless steel materials, in line with
the GMP requirements.
. Filling volume and speed of filling can be arbitrary regulation, filling high
accuracy.
Technical Parameters Bottom price single nozzle cream filling machine 10 to 100g Model 404 engineer mansy mark
| Machine model | 404a | 404b | 404c | 404d | 404e | 404f |
| Filling speed | 10-35 bottles/min(take water for example) | |||||
| Filling range | 10-100ml | 30-300ml | 50-500ml | 100-1000ml | 300-3000ml | 500-5000ml |
| Air pressure | 0.4~0.6mpa | |||||
| Filling error | ±1% | |||||
| Machine size | 806(L) × 180(W) ×690(H)mm | 880(L) ×230(W) ×665(H)mm | 880(L) × 230(W) ×665(H)mm | 1065 (L) ×230(W) ×665(H)mm | 1250(L) ×400(W) ×300(H)mm | 1390(L) ×420(W) ×380(H)6mm |
| Machine weight | 42Kg | 45Kg | 48Kg | 52Kg | 64Kg | 86Kg |
