Automatic Vertical Sugar Salt Rice Instant Coffee Bag Pouch Sachet packing machinery model 902 Engineer mansy international brand
This machine is suitable for food, chemical, pharmaceutical, seasoning powder, granule and fine
particle packing; particularly suitable for packaging milk powder, bean milk powder, sesame paste,
sugar granule, wheat powder and so on;
Characteristic:
It can full automatic carry out the process of sachet forming, filling and sealing, also can add date and batch number printing device, gas- flushing device, punch (a hole in the sachet for hanging to display the product) and conveyer belt.
Packaging products can select by tooth type cutting, scissors type flat cutting or with one notch cutting.
With easy tearing mouth device, for customers to open the packaging bag conveniently.
The machine can adjust the length of the packaging film, weight, temperature and vibration stepless packaging speed without stopping its working, rapidly replace the film and the maintenance of equipment. Greatly improve efficiency, avoid packaging film and material waste, saves the cost.
Stepping motor with photoelectric switch position, conveniently length adjust, precisely bag-making.
Greatly enhance the stability of equipment, lower noise, conveniently cleaning, reduce the maintenance cost.
Digital temperature control table, conveniently adjust temperature.
Film feeding pinch mechanism, film with a little static can also be used.
High working speed, prevent Material leakage, no more dust.
Optional device Automatic Vertical Sugar Salt Rice Instant Coffee Bag Pouch Sachet packing machinery model 902 Engineer mansy international brand
- Date & batch printer
- Gas-flushing device
- Easy tear opening
- Numerical control cutter
5.Touch display menu
- Frequency control of motor speed
- Mixing system
- Keep warm system
Technical parameter Automatic Vertical Sugar Salt Rice Instant Coffee Bag Pouch Sachet packing machinery model 902 Engineer mansy international brand
| Model | 902 | 903 |
| Film width | Max 280mm, 14inch | Max 420mm, 18inch |
| Bag size(mm) | L:50-280mm,3-12inch | L:50-300mm,3-12inch |
| W:60-140mm,3-7inch | W:60-200mm,3-9inch | |
| Packing speed | 15-36 pcs/min | |
| Bag type | Back seal | |
| Packing range | 20-100g | 100-500ml, 100-500ml-1000 ml >1200 ml (custom-made) |
| Outer size(L x w x H) | 1200*1100*1800mm | 1200*1100*2000mm |
| Total power | 220V/110V AC 50HZ 1.2KW | 220V/110V AC 50HZ 2.2KW |
| Machine weigh | 320kg | 360kg |
