الوصف
Automatic Fruit Juice Ice Lolly Jelly Stick Sachet Filling Packing Machine model 503 Engineer mansy international brand
10-200ml 0-8oz flow ability liquid stick vertical packing machine for ice pop, ice lolly, juice
Model: 504
Use Automatic Fruit Juice Ice Lolly Jelly Stick Sachet Filling Packing Machine model 503 Engineer mansy international brand
This machine is suitable for strip packing food, chemical, pharmaceutical, condiments, daily necessities and other liquid materials. Such as jelly, fruit juice,ice lolly, ice pop, drink, etc.
Character: Automatic Fruit Juice Ice Lolly Jelly Stick Sachet Filling Packing Machine model 503 Engineer mansy international brand
Full automatic carry out the process of strip-forming, material-filling, sides-sealing, strip-cutting and quantity-counting.
Date & batch number printing device can be added.
Packaging products can select by tooth type cutting, scissors type flat cutting or with a ‘straight- line’ notch cutting. With easy tearing mouth device, for customers to open the packaging bag conveniently.
Using Stainless steel Insulation barrels, healthy and reliable, easy to clean.
Stepping motor with photoelectric switch positioning, conveniently adjust length without stopping the machine working, high precision bag forming.
It can easily adjust the products packing weight, temperature, packing speed.
Intelligent cursor positioning 1-2 bag can be fixed in place.
Seal with intelligent temperature control table, the sealing error control within 2 degrees.
Numerical control cutter, can set 2-99 bags(bags connected) automatic counting and then cutting.
When the roll film is end, machine will stop running automatically. It can automatic detect the fault.
Optional device Automatic Fruit Juice Ice Lolly Jelly Stick Sachet Filling Packing Machine model 503 Engineer mansy international brand
- Date & batch printer
- Gas-flushing device
- Easy tear opening
- Numerical control cutter
5.Touch display menu
- Frequency control of motor speed
- Mixing system
- Keep warm system
Technical parameter Automatic Fruit Juice Ice Lolly Jelly Stick Sachet Filling Packing Machine model 504 Engineer mansy international brand
| Roll of film, s width | Max 280mm,11inch |
| Bag size (length width) | L:40-180/300mm,2-11linch
W:10-130mm,2-6inch |
| Packing speed | 40-80pcs/min |
| Bag forming type | Back seal |
| Measuring range | 10-200ml,0-8oz |
| Power voltage | 220 vac/50hz |
| power | 1.2kw |
| dimension | (l*w*h) 1100*900*200mm |
| Weight of machine | 320kg |
